N9038B MXE EMI Test Receiver, 3 Hz to 44 GHz

Name: N9038B MXE EMI Test Receiver 3 Hz to 44 GHz
Brand: keysight Technologies
Price: 1 USD

Buy cheap N9038B MXE EMI Test Receiver, 3 Hz to 44 GHz product

Brand Name : keysight Technologies

Model Number : N9038B MXE EMI Test Receiver, 3 Hz to 44 GHz

MOQ : 1

Price : Negotiation

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : In Stock

Delivery Time : 1~3 Working Days

Packaging Details : Carton

Certification : ISO17025

Frequency : 3 Hz to 44 GHz

DANL at 1 GHz, RF preselector on : -167 dBm

Maximum Analysis Bandwidth : 160 MHz

Real-Time Bandwidth : 160 MHz

Phase Noise at 1 GHz, 10 kHz offset : -114 dBc/Hz

Contact Now

N9038B MXE EMI Test Receiver, 3 Hz to 44 GHz

The Keysight N9038B is a standards-compliant MXE EMI test receiver and diagnostic signal analyzer built on an upgradeable platform. You choose the frequency coverage you need to fully test devices with outstanding accuracy and sensitivity across required ranges.

Perform EMC tests with a standard-compliant receiver: CISPR 16-1-1 & MIL-STD-461
Keep the test queue flowing with the accuracy, repeatability and reliability you need to test with confidence
Reduce overall scan time with time domain scanning enabled by fast FFT scans

Easily identify the frequencies of peak emissions prior to final measurement with monitor spectrum
Get enhanced diagnostics using spectrum and real-time analysis, strip chart, markers, span zoom, zoom span, and spectrogram
Evaluate emissions and identify suspect signals using EMC measurements through the front panel or remotely with software

Key Specifications

Frequency

DANL @1 GHz

Maximum Analysis Bandwidth

Maximum Real-Time Bandwidth

Phase Noise @1 GHz (10 kHz offset)

3 Hz to 44 GHz

-174 dBm

160 MHz

-114 dBc/Hz

Bandwidth Options:

10 MHz

25 MHz

85 MHz

160 MHz

DANL @1 GHz:

-174 dBm

Frequency:

3 Hz to 44 GHz

Frequency Options:

3 Hz to 3.6 GHz

8.4 GHz

26.5 GHz

and 44 GHz

Maximum Analysis Bandwidth:

160 MHz

Maximum Real-Time Bandwidth:

160 MHz

Performance Level:

◆◆◆◆◇◇

Phase Noise @1 GHz (10 kHz offset):

-114 dBc/Hz

N9038B MXE EMI Test Receiver, 3 Hz to 44 GHz

Learn more at:

https://www.keysight.com/us/en/assets/7018-02885/brochures/5990-7422.pdf
